Frost Jingyuan 75 Table Lamp

GJT-JY75
1. Intelligent dimming and color adjustment, voice control + Tuya APP control + touch multi-level control, achieving: illumination 10~800lx, color temperature 2700~5700K can be adjusted at will.
2. Shading: 100% shading, achieve the tree shadow lighting effect of "seeing light but not lamp, seeing light but not shadow".
3. Anti-glare: UGR<,10, measured UGR: 5.7, eliminate glare hazards
4. Blue light hazards: The measured desktop retina blue light hazard radiation brightness value LB (W/㎡/sr) is 0.3491, and the national standard requires less than 100, eliminate blue light hazards.
5. Light source: military-grade Purui full-spectrum LED lamp beads, 2835, 3V, 0.2~0.5W, 12B12C*2, 288 pcs.
6. Material: PC unbreakable light cover + ADC12 alloy aluminum lamp head + aviation aluminum lamp pole + steel plate base + 3M silicone anti-slip pad.
7. Maximum luminous flux: 8385lm, luminous efficiency: 92lm/w, Ra: 98.4, maximum power: 106w, which can meet the lighting needs of 6-28㎡ study, bedroom, children's room, piano room, dressing room, office, study room, and desktop under the bed of college students.

Protection level

CLASS Ⅲ

Light source specifications and quantity

Military-grade full-spectrum LED lamp beads, 2835, 3V, 0.2~0.5W, 12B12C*2, 288 pcs

Lighting effect

The maximum luminous flux is 8381.31lm in neutral light, 90.08lm/w in light efficiency, and 93.04w in power, the maximum luminous flux is 4993.2lm in white light, 91.15lm/w in light efficiency, and 54.78w in power, the maximum luminous flux is 4542.15lm in yellow light, 84.27lm/w in light efficiency, and 53.9w in power

Light level

AAAAAA

Light blocking

Shading degree: 100%

Anti-glare

UGR<10 (minimum 4.0, glare eliminated)

Control System

Dimming and color adjustment voice control + Tuya APP control + touch multi-level dimming and color adjustment control

Technological advancement

Series of patents: invention patent + international PCT + utility model patent + appearance patent

Certification





Implementation Standards



GB/T 7000.1-2023,GB/T 7000.201-2023,GB/Z 39942-2021,

GB17625.1-2022,GB/T17743-2021,GB/T9473-2022,Q/GJTL1913.8-2024


Material

PC unbreakable light cover + 6063A grade, first-grade aluminum lamp holder and lamp pole + steel plate base + 3M silicone anti-slip pad

Product Net Weight

4.96KG

Specifications and dimensions

L880×W54×H790mm

Application

Study, bedroom, children's room, piano room, dressing room, dining room, living room, office, study room, reception room, etc.

Note: This parameter is for reference only. For functional parameters of other models, please refer to the product nameplate on the lamp.
×
